Used Ultrasonic Systems Prism 400 Spray Coater – 400mm x 400mm | 600mm/s | Tilt & Rotation | Built 2023

DOWNLOAD ALL PHOTOS FOR THIS ITEM WITHOUT AARON WATERMARK

SELL US YOURS

Stock # 53938001

Used Ultrasonic Systems Spray Coater, Model Prism 400. 600mm/second (20"/sec) coating speed; 400mm x 400mm x 125mm (15.75" x 15.75" x 4.72") application area; Up to 45 degrees in two directions tilt motion; 0-90 or 0-180 degree theta rotation range; Lead screw, stepper drive Z motion; Precision ball screw X/Y platform; 16" max. X and Y axis stroke; 0-150 degrees C (32-302 degrees F) heat plate set point, configurable up to 200 degrees C (392 degrees F). With stand. 1/50-60/220V. Built 2023.

SPECIFICATIONS

Manufacturer	UltrasonicUltrasonic
Model	Prism 400
Serial #	202308700001
Category	Lab EquipmentLab Equipment
Subcategory	Lab EquipmentLab Equipment

Used Equipment Facts About This Machine

Manufacturer Information:

Brand: Ultrasonic Systems
Model: Prism 400
Type: Ultrasonic Spray Coating System
Year Built: 2023
Condition: Used
Power: 1/50-60 Hz/220V

Description:

This Used Ultrasonic Systems Prism 400 Spray Coater, built in 2023, is a precision ultrasonic spray coating system designed for high-speed, uniform application of coatings on substrates up to 400mm x 400mm in size. With a coating speed of 600mm/second (20”/sec) and a motion system featuring X/Y precision ball screws, Z-axis stepper drive, and programmable tilt and rotation capabilities, this unit is ideal for demanding production environments. Includes a heated plate with setpoint range from 0°C to 150°C, configurable up to 200°C (392°F), and comes mounted on its own stand.

Specifications:

Model: Prism 400
Application Area: 400mm x 400mm x 125mm (15.75" x 15.75" x 4.72")
Coating Speed: 600 mm/sec (20 inches/sec)
Axis Stroke: Max. 16" X and Y
Motion System:
- X/Y: Precision ball screw platform
- Z: Lead screw, stepper drive
Tilt Motion: Up to 45° in two directions
Theta Rotation Range: 0–90° or 0–180°
Heated Plate:
- Setpoint: 0–150°C standard (configurable to 200°C / 392°F)
Power: 1 Phase / 50–60 Hz / 220V
Includes: Floor stand
Year: 2023
Condition: Used

Features:

High-speed ultrasonic spray application
Multi-axis motion for 3D surface and angled coating
Fully programmable tilt and rotation for complex geometries
Stepper-driven Z-axis for precise vertical control
Precision linear X/Y motion for consistent application
Configurable heated plate up to 200°C for curing or process-specific needs
Integrated on stand for easy deployment and access
Ideal for conformal coatings, thin films, electronics, and advanced materials

Applications:

Conformal coating for electronics/PCBs
Semiconductor wafer spray processing
Thin-film deposition on sensors and substrates
Solar cell material application
Biomedical coating on components
Fuel cell layer application
Research and development in materials science
Microfluidics and MEMS coating
Ceramic and polymeric coating in lab settings
Precision lab or pilot-scale spray coating processes

What might this be used for?

Coating printed circuit boards for moisture and chemical resistance
Applying uniform thin films for semiconductor and MEMS devices
Producing solar cells and energy devices with precision layer deposition
Coating biomedical devices with functional or protective layers
Performing high-speed lab-based R&D spray trials
Developing or validating spray coating processes for advanced manufacturing
Thermal-cured material application with heated plate
Spraying onto angled or complex surfaces using tilt and rotation
Pilot-line coating operations for materials testing
Automation-friendly spray system integration
